BORA Basic Compact Radiant Cooktop

The radiant heating elements are heated and emit heat to the cookware. All kinds of cookware can be used, from ceramic to copper pots.

Particularly quick initial heating

Extractor opening overflow protection

Features

Automatic heat-up function

When the automatic heat-up function is activated, the cooking zone works at full power for a certain time and is then automatically reset to the previous level.

Compact size

Thanks to its compact dimensions and a cooktop depth of 515 mm, the system is compatible with standard rows of kitchen units.

Minimum volume

Thanks to the optimum airflow through the appliance and the use of a twin fan system, BORA Basic is extremely quiet even on high power levels. So it won’t distract you from your cooking and your conversations won’t be disturbed.

Simple cleaning

All parts that come into contact with cooking vapours can be easily removed through the wide and easily accessible air inlet opening and simply and easily cleaned in the dishwasher, where they take up very little space.

Oversized 4 24 cooking surface

Thanks to the operating panel not restricting the cooking area and the optimum arrangement and size of the cooking zones, there is plenty of space for two large pots or pans (up to 24 cm) to be placed one behind the other.

Cooking zone timer, quick timer

The automatic cut-off function automatically switches off the selected cooking zone once a preset time has lapsed.

Genuine stainless steel grease filter

Specification

• Multiphase supply voltage: 380–415 V 2N/3N

• Supply voltage 1-phase: 220–240 V

• Frequency: 50–60 Hz

• Maximum power consumption: 7000 W

• 3-phase fuse protection/power supply: 3 × 16 A

• 2-phase fuse protection/power supply: 2 × 16 A

• 1-phase fuse protection/power supply: 1 × 32 A

• Dimensions (width × depth × height): 760 × 515 × 196 mm

• Weight (incl. accessories/packaging): 25 kg

• Surface material: Glass ceramic

• Cooktop extractor power levels: 1, 2, P

• Cooktop power levels: 1–9, P

• Size of exhaust opening: 650 × 90 mm

• Size of front cooking zones Ø: 210 mm

• Size of rear cooking zones Ø: 140 mm

• Front cooking zone output: 2300 W

• Rear cooking zone output: 1200 W

• Output of front cooking zones on power setting: 3000 W

• Filter material: Activated charcoal with ion exchanger

• Maximum filter service life: 150 hrs (1 year)

• Duct connection: BORA Ecotube
